Position 45L4

1¢ Franklin Issue of 1851-1857, PLATE 4
Position 45L4

Type III, Relief E
Issued both imperforate (Scott 8) and perforated (Scott 21).

Plating Notes:
Dot below N of ONE. This dot, no doubt from foreign matter adhering to the transfer roll, occurs on many E relief positions, some but not all of which are illustrated on the Neinken mats.

Dots or squiggle in the right margin. These marks, no doubt from foreign matter adhering to the transfer roll, occur on many E relief positions, some but not all of which are illustrated on the Neinken mats.

Courtesy of George Kopecky

Figure 1. (BELOW) Blurs and dots of color above the PO and ST of POSTAGE as illustrated in the Neinken plating diagram.

Figure 2. (BELOW) A heavy dot below the N of ONE, and blur of color in the C of CENT as illustrated in the Neinken plating diagram. The plating marks illustrated below Ornament G in the plating diagram does not exactly represent what is visible on this patient. A small dot in the left plume attributable to a bit of foreign matter adhering to the transfer roll starting with 46L4 and carrying over to the next six plate entries, 86-45-85-44-84-43L4. This dot is shown on the Neinken 46L4 mat, but not on any of the other positions.

Figure 3. (BELOW) A horizontal plate scratch or layout line not illustrated in the plaing diagram. It should be noted that a similiar line can be found on position 49L4. On 49L4, the line is not horizontal and tilts downward to the right.
